12.8V 150Ah LiFePO4 Prismatic Battery Pack for Solar Storage/ Marine

Model: JLS-12150FP-4

Battery Type: LiFePO4

Battery Voltage: 12.8V

Battery Capacity: 150Ah

Application: Energy Storage, Power Supply, Marine, etc


Description

● Light, powerful, and offering a very long viewing time, this Lithium-ion battery is particularly suitable for cyclic use, when batteries are frequently charged and discharged.

● Built-in BMS. 100% of the capacity is available for your needs, without voltage drop!

● Lithium batteries (Lithium Iron Phosphate) offer many advantages over lead batteries.

● They have a much faster-charging capacity, which allows you to use even the smallest amount of sunlight without being limited by the internal resistance of the battery.

● A lead battery, depending on its capacity will be limited in charging power.

● With lithium, you will charge with the maximum of what the controller can give.

● Unbeatable also when discharging, they easily withstand very fast discharges.

● Comparing the price per ampere-hour available (with lithium you have a very high depth of discharge) we can see that the price per Ah available is just a little bit more expensive than lead batteries.

● Lithium batteries have many advantages.

● High number of charge/discharge cycles :

● Service life at 80% depth of discharge (DoD) ≥3000

● Service life at 50% depth of discharge (DoD) LiFePO4 battery ≥ 4500


ItemsParameter
Battery TypeLithium prismatic LiFePO4 battery
Nominal Voltage12.8V
Nominal Capacity200Ah
Energy2560WH
Dimensions (L x W x H)520x240x220 mm
Weight25kg
Case MaterialABS
Efficiency99%
Self Discharge<1% per Month
Parallel Applicationmax. 6 parallels connected application
Max. Continuous Charge Current80 A
Max. Continuous Discharge Current80 A
Operation Temperature Range-20~60℃
Voltage at end of Discharge14.6V
Working Voltage10-14.6V
Discharge Temperature-4 to 140 ºF (-20 to 60 ºC)
Charge Temperature32 to 113 ºF (0 to 45 ºC)
Storage Temperature23 to 95 ºF (-5 to 35 ºC)
Cycle Life> 3000 cycles @80%DOD
Self-Discharge RateResidual capacity: ≤3%/month; ≤15%/years
Reversible capacity: ≤1.5%/month; ≤8%/years
Storage Temperature & Humidity RangeLess than 1 month: -20℃~35℃, 45%RH~75%RH
Less than 3 months: -10℃~35℃, 45%RH~75%RH
Recommended storage environment:  15℃~35℃, 45%RH~75%RH
