LiFePO4 Rechargeable Battery 12V 24V 7ah 9ah 12ah 15ah 17ah 20ah Solar Battery Lithium Batteries with BMS

Cycle life：100% DOD 3000 times

Battery Type：LiFePO4

Rated Capacity：7Ah

Rated Voltage：12.8V

Battery cell：21700 Battery Cell

APP：Support customized

Compitable Inverter Brand：SMA, Growatt, Solax, Solis,DEYE,Sungrow, Sofar, Voltronic, Goodwe, etc.

Inquire Now Next Product

Description

Notice

Model	ZWN-1207LFP	ZWN-1220FP	ZWN-1250FP	ZWN-12100FP	ZWN-12200FP	ZWN-12300FP
Nominal Voltage	12.8V
Nominal Capacity @25℃	7AH	20AH	50AH	100AH	200AH	300AH
Nominal Energy @25℃	89.6WH	256WH	640WH	1280WH	2560WH	3840WH
Battery Cell Type	Cylinder (32700 or 26650)		Prismatic 50Ah	Prismatic 100Ah	Prismatic 200Ah	Prismatic 300Ah
Configuration (SP)	4S1P	4S3P	4S3P	4S1P	4S2P	4S3P
Max. Continous Charge Current @25℃	7A	20A	50A	100A	200A	300A
Max. Continous Discharge Current @25°C,10s	7A	20A	50A	100A	200A	300A
Dimension (mm)	1526594mm	18017277mm	229138208mm	326171215mm	522240218mm	520240218mm
Weight (KG)	1.1KG	3KG	7KG	13.5KG	25KG	30.5KG
DC Resistance	≤10mΩ
Full Charged Voltage	14.6V
Discharge Cut-off Voltage	10V
Operate Temperature Range	Charge: 0˚C~55˚C; Discharge: -20˚C~60˚C; Storage: -20˚C~45˚C
Humidity (non-condensing)	Max. 95%
Terminal Type	F1 terminal		Screw terminal
Cover Sealing type	Screw / gel sealing optional
Waterproof	IP65
Cycle life	100% DOD Cycles @ 25°C, 1C/1C: >2000 times; 80% DOD Cycles @ 25°C, 1C/1C: >3000 times 50% DOD Cycles @ 25°C, 1C/1C: >5000 times
Service Life	5-10 years
Warranty	3 years
