Model: ES-BOX2
Battery Type: LiFePO4
Battery Voltage: 51.2V
Battery Capacity: 100Ah
Communication: RS485/ CAN
Application: Solar Household Energy Storage ESS
Description
Notice
Every solar purchase includes powerwall, a compact home battery that reduce your reliance on the grid by storing your solar energy for use when the sun isn’t shining. You can add additional Powerwall units to your order to further lower your carbon footprint and to prepare your home for power outages.
Powerwall is an integrated battery system that stores your solar energy for backup protection when the grid goes down. Your system detects outages and automatically recharges with sunlight to keep your appliances running for days.
With easy installation and a minimalist design, Powerwall complements a variety of home styles and solar systems. The compact, all-in-one construction features versatile mounting options for indoor spaces.
Model | ES-BOX2 5.12KWH |
Battery Type | LiFePO4 |
Energy | 5120Wh |
Rated Capacity | 100Ah |
Rated Voltage | 51.2V |
Battery cell | 3.2V 100Ah Prismatic Battery Cell |
Configuration (*S*P) | 16S1P |
Discharge Cut-off Protect Voltage | 40V |
Charge Cut-off Protect Voltage | 58.4V |
Max. Charge Current | 100A |
Max. Discharge Current | 100A |
Communication Port | CAN, RS485 |
Compatible Inverter Brand | SMA, Growatt, Solax, Solis,DEYE,Sungrow, Sofar, Voltronic, Sorotec, Studer, etc. |
Parallel | Max. 8 units in Parallels to get 40.96kWh. |
Cycle life | 80% DOD 5000 times |
L*W*H (mm) | 600*510*173 |
Net Weight (KG) | 63.5KG |
Cooling | Natural cooling |
Environment | Indoor |
Mounting options | wall mount |
Discharge Temperature (℃) | -10℃~+60℃ |
Charge Temperature (℃) | 0℃~+45℃ |
Storage Conditions | –20°C to 30°C (–4°F to 86°F)Up to 95% RH, non-condensingState of Energy (SoE): 25% initial |
Maximum Elevation | 3000 m (9843 ft) |
